Temperature meter
- innovative, robust, reliable

The robust and reliable TEM-EX-L temperature meter for general mining applications is used for measuring the temperature of liquid and gas media. With cost efficiency, optimal use of space, reliable operation, easy installation and commissioning the TEM-EX-L fulfills the requirements of modern process measurement technology.

In addition to the usual used 5-15 Hz output in underground mining, TEM-EX-L devices also have a 4-20 mA two-wire current loop. Because they use two-wire technology, our TEM-EX-L series make planning and implementing new plants considerably easier through lower installation effort. In addition, the technology increases the interference immunity of the transmitted measurement signal.

The temperature measuring device features a G½ thread process connection. The measurement sensor length is variable and can be chosen ranging from 30…1000 mm.

• High precision quartz sensor or semiconductor sensor
• Robust and reliable at different process conditions
• Excellent accuracy and repeatability
• High level of reliability and measurement stability
• High profitability as it is wear and maintenance free
• Easy installation and commissioning
• Compact design
